Forney 314 Arc Welder, 230 V Input, 235 A, 1-Phase, 24 ga to 1/2 in Thick, 50 % Duty Cycle

Product Overview

• This welder has a duty cycle of 20% at 230 A, 50% at 150 A AC, 20% at 180 A and 35% at 135 A DC. The electroholder cable is 3 m 25 sq-mm, the earth clamp cable is 2 m 25 sq-mm, both with dense connector. Input cable American wire gauge (AWG) 10, 2.5 mm. 50 A plug. CSA certified Cat #00329, wheel and handle kit for "Forney" 00313 and 00314 must be purchased separately. Weighs 116 lb (52.62 kg).
• bullet: Ready to weld right out of the box, only handle assembly required
• bullet: Ready to weld right out of the box, only handle assembly required
• bullet: AC/DC CC welding from 24 ga to 1/2 in thickness at 45 to 235 A
• bullet: Dinse style connection provides easy polarity change and cable repairs
